Doors

Skill Level: Medium



Our Recommended Tools
[Mouse with Auto Pressure Indicator]
KA168K
[55mm circ saw]
CD601
[12V Hammer Compact Drill]
CP122K
[4,8V 3 position screwdriver]
HP9048K
[650W Rebating Planer with 2mm Depth of Cut]
KW712
[AutoTape Measure]
ATM100
Additional Tools
Door
Hinges
Screws
Marking Gauge
Chisel
Mallet
Try Square


All You Need



Door, hinges, sander or sandpaper, screws, marking gauge, chisel, power drill, planer, mallet, panel or circular saw, electric screwdriver, tape measure and try square.

Why Do Doors Matter?

Obviously, doors provide privacy in the home and help retain heat and keep cold out. However, they also have a decorative function, providing an attractive divider between two rooms whilst enhancing the décor in the process. Gates are not a first line of security, but they are useful for keeping out unwanted visitors, especially the four-footed variety. A quality door or gate also creates the right first impression.


Step-By-Step


Most doors come in standard sizes. You can shave off up 19mm from a panel door, but only 10mm all round from a flush door, as its internal structure is weaker When thinking about how to trim your door, remember doors need to be smaller than frames Flush exterior doors should be 2mm smaller all round and panelled doors 3mm.

To measure how much of the door to remove, put it in place, supported by wedges. Lightly mark with a soft pencil where to plane down the wood.

If there is more than 5mm of wood to remove, lay the wood flat, saw it and then plane down the final part

Tip
Doors can be heavy and cumbersome. Have a friend help you lift and hold.



When planing, use strokes with grain along the long edges and plane towards the centre at corners, to avoid cutting or splitting the wood. Be sure to check the door against the doorframe regularly while cutting it down When the fit is right, plane a gentle slope onto each door stile towards doorstop. This will stop the top and bottom of the door from sticking Attach hinges. Hold door in place and mark positions of hinges The number and type of hinges will depend on the type and location of the doors. Generally, interior doors will only need two pressed-steel hinges, which should be 75mm pressed-steel cranked butt hinges, unless there is a specific need for another hinge type

Exterior doors are heavier and require three hinges. Pressed steel will be strong enough for flush doors. For panel doors, or extra reassurance, cast iron will be needed



Brace door against frame and note hinge positions. Flush doors will have recesses marked out for hinges. If these match after trimming the door, mark top and bottom of recesses on frame

Tip
Be sure to position the hinges correctly. Pressed-steel cranked butt hinges should have the whole knuckle projecting from door. A cast-iron hinge should sit with the knuckle level with door and frame.



If the recesses are no longer in the right place, or you have a panel door, you will need to lengthen or create space for the hinges. Hold hinge against door then trace around with craft knife

Tip
At this stage, only use one screw to fix the door. You may need to make adjustments.

Use gauge to mark thickness of hinge flap, then cut into the traced line with chisel. Make a series of cuts inside this rectangle, each 6mm apart. With flat side of chisel pointed downwards, carefully cut away unwanted wood


Holding the door open on wedges, screw hinge to frame. The heads of the screws should be exactly on a level with the hinge flap. If they are not, the protruding head will keep the door from closing


To prevent this, use a Black and Decker power drill with a twist bit to countersink the screw, or remove and replace it with a lower gauge size. While the door, frame and hinges are only connected by one screw each way, remove the wedges and see if the door will open and close smoothly. If not, you will have to reposition the hinges When the door is correctly positioned, add other screws. Your door is now fixed - an open and shut case
